Name: 520 kw Generator diesel Power by WEICHAI Engine 6M33D633E200 Leroy Somer Alternator Generators 650 Kva Generador
Brand: FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
SKU: 6M33D633E200
Price: 1,600.00 USD
Availability: InStock

Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα

Χαρακτηριστικά

Προδιαγραφές

Επισημαίνω:

520 kW silent diesel generator

650 kva Weichai engine generator

Leroy Somer alternator diesel generator

Βασικές πληροφορίες

Τόπος καταγωγής: Κίνα

Μάρκα: WEICHAI

Πιστοποίηση: ISO 9001

Αριθμό μοντέλου: 6M33D633E200

Πληρωμής & Αποστολής Όροι

Συσκευασία λεπτομέρειες: 420*130*195 εκ

Χρόνος παράδοσης: 30 ΕΡΓΑΣΙΜΕΣ ΗΜΕΡΕΣ

Δυνατότητα προσφοράς: 500 τμχ το μήνα

Εκθεσιακός χώρος

520 kw Generator diesel Power by WEICHAI Engine 6M33D633E200 Leroy Somer Alternator Generators 650 Kva Generador

Περιγραφή προϊόντων

Weichai 6M33D633E200 Diesel Generator Set

Our Weichai 6M33D633E200 Diesel Generator is a high-performance, heavy-duty generator set designed for reliable prime and standby power applications. Engineered with the renowned Weichai engine, this 520kW unit features a robust soundproof canopy, making it ideal for applications requiring low noise operation without compromising power and durability. Perfect for construction, industrial, commercial, and emergency backup use.

Power Specifications

Parameter	Prime Power	Standby Power
Rated Power (kVA)	650	715
Power Rating (kW)	520	572
Frequency (Hz)	50
Engine Model	6M33D633E200
Engine Speed (RPM)	1500
Phase	3
PF	0.8
Control System	Digital
Rated Voltage (V)	400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time	≥ 8h @ 75% load

PRP Prime Power: Available for unlimited annual hours in variable load applications according to GB/T2820-97; includes 10% overload capability for 1 hour within 12 hours of operation.

ESP Standby Power: Applicable for supplying emergency power during utility power interruptions. No overload, utility parallel, or negotiated outage operation capability available.

Dimensions and Weight

Model	BWC715	BWC715S
Type	Open	Silent
Length (L) mm	3800	4300
Width (W) mm	1740	1600
Height (H) mm	2745	2250
Tank Capacity (L)	1196	1196

Engine Specifications

Engine Model & Manufacturer	6M33D633E200 (WEICHAI)
Emission Certification	----
Number of Cylinders	6
Cylinder Arrangement	In-line
Cycle	L-Type
Aspiration	Turbocharging and Intercooling
Bore x Stroke	150 x 185 mm
Cubic Capacity	19.6 L
Compression Ratio	15.0:1
Prime Power / Speed	575 kW / 1500 rpm
Standby Power / Speed	639 kW / 1500 rpm
Governor Type	Mechanical Pump
Cooling System	Force Water Cooling Cycle
Transient Frequency Deviation	-0.833333333
Total Lubrication System Capacity	61 L
Coolant Capacity (Engine Only)	43.93 L
Fuel Consumption @ 100% Load	575 g/kWh @ 1500 rpm
Starter Motor	DC 24V
Charge Alternator	DC 24V

Alternator Specifications

Alternator Brand	BOBIG
Alternator Manufacturer	FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model	BW-354F
Alternator Rated Power	520kW / 650kVA
Rated Voltage (V)	230V / 400V
Rated Frequency	50Hz
Connecting Type	3 Phase and 4 Wire
Number of Bearings	1
Protection Grade	IP23
Altitude	≤1000m
Exciter Type	Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class	H Class
Telephone Influence Factor (TIF)	≤50
THF	≤2%
Voltage Regulation, Steady State	≤±1%
Transient State Voltage	≤-15%~+20%

Control Panel - DSE 6120

Auto start and auto mains failure control module with alternator frequency & CAN speed sensing.

Key Benefits

Automatically transfers between mains (utility) and generator
Hours counter for accurate monitoring and maintenance
User-friendly set-up and button layout
Multiple parameters monitored & displayed simultaneously
Configurable for wide range of applications
PLC editor for user configurable functions

Key Features

4-line back-lit LCD text display
Multiple display languages
Five-key menu navigation
LCD alarm indication
Customizable power-up text and screen images
DSENet® expansion compatibility
Data logging facility
Internal PLC editor
3-phase generator sensing and protection
Generator current and power monitoring (kW, kvar, kVA, pf)
Real time clock
Engine run-time scheduler
IP65 rating (with optional gasket)

Available Options

Engine	Alternator	Fuel System	Generating Set
Water Jacket Preheater Oil Preheater Oil manual pump	PMG excitation Space heater Winding temperature measuring	12 / 24 hour base tank Bunded fuel tank External fuel tank Automatic fuel feeding Switch between external tank and base tank (three-way valve)	Deepsea, ComAp, Smartgen etc. controller Trailer Tools with the machine
