Name: Factory Price Open/Silent Type Quanchai Diesel Generator 12KW/15KVA Power Supply Water Cooling
Brand: FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
SKU: N485D
Price: 2,965.00 USD
Availability: InStock

Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα

Χαρακτηριστικά

Προδιαγραφές

Ταχύτητα: 1500 σ.α.λ

Συχνότητα: 50/60Hz

Ονομαστική ισχύς: 5KW έως 2000KW

Τύπος εξόδου: AC Τριφασικό

Τύπος: Ανοιχτό ή Αθόρυβο (Σούπερ Αθόρυβο)

Χρώμα: Κατά την απαίτησή σας, Προσαρμοσμένο

Επισημαίνω:

Quanchai silent diesel generator 12KW

water cooling diesel generator 15KVA

open type diesel generator with warranty

Βασικές πληροφορίες

Τόπος καταγωγής: Κίνα

Μάρκα: QUANCHAI

Αριθμό μοντέλου: N485D

Πληρωμής & Αποστολής Όροι

Συσκευασία λεπτομέρειες: κόντρα πλακέ

Χρόνος παράδοσης: 40 εργάσιμες ημέρες

Όροι πληρωμής: L/C, T/T

Δυνατότητα προσφοράς: 50 σετ το μήνα

Εκθεσιακός χώρος

Factory Price Open/Silent Type Quanchai Diesel Generator 12KW/15KVA Power Supply Water Cooling

Περιγραφή προϊόντων

Factory Price Open/Silent Type Quanchai Diesel Generator 12KW/15KVA Power Supply Water Cooling

High quality water cooling QUANCHAI diesel generator available in both open and silent configurations to meet diverse operational requirements.

Key Features

Equipped with famous brushless alternator brands: Leroy Somer, Marathon, BOBIG, Mecc Alte
50°C radiator with fan for optimal engine cooling during extended operation
Advanced control systems including generator set control, ATS system, remote control, and parallel operation
High-quality steel canopy construction (2MM to 6MM thickness)
High-density sound-absorbing material for effective sound insulation and fireproofing
12V/24V DC battery with charger and connecting wires
10-12 hours fuel tank with fuel indicator for continuous operation
High protection class control box (IP55) with waterproofing, electric leakage protection, and breaker
Turn-back type air inflow & outlet design reduces noise and improves engine efficiency
Practical design with bottom holes for forklift, water outlet, and oil outlet for easy maintenance
Double open doors on both sides for comprehensive engine and alternator access
Available in silent, super silent, soundproof, trailer type, and container type configurations
Compliance with major standards: GB/T2820, ISO8528, IEC34, CE, EPA Tier4

Technical Specifications

General Information	Prime Power	Standby Power
Rated Power (kVA)	15	17
Power Rating (kW)	12	13
Frequency (Hz)	50
Engine Model	N485D
Engine Speed (RPM)	1500
Phase	3
PF	0.8
Control System	Digital
Rated Voltage (V)	400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time	≥ 8h @ 75% load

PRP (Prime Power): Available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.

ESP (Standby Power): Applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.

Dimensions and Weight

Model	BQ17 (Open Type)	BQ17S (Silent Type)
Length (L) mm	1350	1950
Width (W) mm	610	850
Height (H) mm	1100	1050
Tank Capacity (L)	28	28

Engine Specifications

Engine Model & Manufacturer	N485D(QUANCHAI)
Model	N485D
Bore*Stroke(mm)	85×95
Total Displacement(L)	2.156
Rated Power(kw)	15.5	18
Standby Power(kw)	17	20
Rated Speed(r/min)	1500	1800
Rated Power For Generator Sets (kva)	15.5	18
Standby Power For Generator Sets (kva)	17	20
Rated Power For Generator Sets(kw)	12.5	14.5
Standby Power For Generator Sets (kw)	13.5	16
Steady State Speed Governing Rate %	≤5
Max Speed On No Load(r/min)	1575
Min Speed On No Load(r/min)	800
Specific Fuel Consumption Rate At Max. Speed (g/kW*h)	≤265
Net Weight (kg)	205
Dimension(LWH) (mm)	773×545×660 (WITHOUT AIR FILTER AND RADIATOR)
Rotation (Viewed From Flywheel)	COUNTER CLOCKWISE
Flywheel House Sizing	SAE4＃
Flywheel House Sizing	SAE7.5″
Number Of Teeth Of The Flywheel	109

Alternator Specifications

Alternator Brand	BOBIG
Alternator Manufacturer	FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model	BW-164D
Alternator Rated Power	12kw/15kva
Rated Voltage (V)	230v/400v
Rated Frequency	50hz
Connecting Type	3 Phase and 4 W
Number of Bearing	1
Protection Grade	IP23
Altitude	≤1000m
Exciter Type	Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class	H class
Telephone Influence Factor (TIF)	≤50
THF	≤2%
Voltage Regulation, Steady State	≤±1%
Transient State Voltage	≤-15%～+20%

Standard Components

Heavy duty diesel engine
Starter battery (with lead acid) including rack and cables
Anti-vibration mount
Flexible fuel connection hoses
Replaceable fuel filter, oil filter & air filter
Exhaust silencer and bellows
Cooling radiator and fan
Operation manuals and circuit diagram documents

Product Images

Front View

Side View

Control Panel

Engine Detail

Alternator View

Silent Type Exterior

Internal Components

Cooling System

Fuel System

Electrical Connections

Full Assembly

Quality Inspection

Specifications and illustrations are subject to revision without notice.
